The measure button allows measuring in any 3D view with 2 clicks. The units and rounding are set to the project units (press UN to see your project units). Changing the base updates the coordinates instantly. Coordinate base used: there are 3 coordinate bases available.Deltas (Δ): this is the difference between coordinate pairs (Δx = pt1X - pt2X).If you expand the dialog box, you can find the following data: You can click on the down arrow to expand the dialog box and reveal other buttons and data. To take another measurement, you can simply press Enter. To start the plugin, click on the 3DMeasure icon located in the Camilion tab, a dialog box will be displayed and you’ll be prompted to select 2 points.Īfter clicking on the second point, the dialog box will be updated to reflect the distance between the 2 points and the delta of each coordinate pair. Add this license key in Help dialog and activate the plugin.The 3DMeasure tool is a plugin for Autodesk® Revit® which allows you to measure in a 3D view by selecting 2 points or an existing edge.A license key will be provided after the purchase of pro version.
After that the pro version is required for generating and sharing 3D PDF files The trial version is for testing the functionality of the plugin. In trial version, the generated 3D PDF will have a footer displaying the source of 3D PDF generation. The trial version is valid for 15 days with complete functionality. The application is available in both versions, trial as well as pro. Option to add all the views/camera to 3DPDF file.
